G30
Siwei Power
Product Advantage
Using the independently developed SW series air-cooled diesel engine, the Siwei Power G series diesel generator set has reliable and strong power source. The engine is air-cooled and does not require adding water; the open-frame design is particularly convenient for maintenance. Strictly selected all-copper motors and AVR automatic voltage regulation ensure stable power output and small waveform distortion. The 35mm thick iron frame and high-quality engineering plastic casters provide overall body strength under harsh environment and ease for transportation. Digital display panel and customizable output modes are suitable for use in multiple scenarios. Customers can use the ATS system to flexibly start and shut down the generator set.
Product Parameter
Model | G20 | G30 | G50 | G70 | |
Rated frequency | Hz | 50/60 | |||
Rated output power | kW | 1.8/2.0 | 2.8/3.0 | 4.6/5.0 | 6.5/7.0 |
Rated voltage | V | 100,110,115,120,127,200,220,230,240 | 100,110,115,120,127,200,220,230,240,110/120,115/230,120/240,127/220,220/380,230/400,240/415 | ||
DC Voltage | V | 12 | |||
DC Current | A | 8.3 | |||
Rated engine speed | rpm | 3000/3600 | |||
Phase number | single phase | single phase/three phase | |||
Power factor | cos(Φ) | 1.0 | 1.0/0.8 | ||
Insulation class | F | ||||
Exciting mode | Automatic regulator(with AVR) | ||||
Panel form | Digital display | ||||
Engine model | SW173F | SW178F | SW186FA | SW195F | |
Fuel type | Diesel 0#(Summer), -10#(Winter), -35#(Chilliness) | ||||
Fuel consumption | g/kW·h | 280/285 | 280/285 | 275/280 | 265/270 |
Fuel capacity | L | 12.5 | |||
Lube oil type | SAE15W40(Summer), SAE10W30(Winter) | ||||
Lube oil capacity | L | 0.75 | 1.1 | 1.65 | 1.65 |
Starting system | Recoil+Electric | ||||
Net weight | kg | 65 | 80 | 115 | 120 |
Package size(L*W*H) | mm | 640*480*520 | 680*480*570 | 760*530*640 | 760*530*640 |
20GP loading quantity | PCS | 132 | 99 | 84 | 84 |
